Tutorial: gRPC with Protobuf

This tutorial will show you how to generate a Mu RPC service definition from a Protocol Buffers protocol file.

Then a follow-up tutorial will guide you through using this service definition to create a fully working gRPC server or client.

This tutorial is aimed at developers who:

  • are new to Mu-Scala
  • have some understanding of Protobuf and .proto file syntax
  • have read the Getting Started guide

This document will focus on Protobuf. If you would like to use gRPC with Avro, see the gRPC with Avro tutorial.

Create a new Mu project

As described in the Getting Started guide, we recommend you use the Mu-Scala giter8 template to create a new skeleton project. This will install and configure the mu-srcgen sbt plugin, which we will need to generate Scala code from a Protobuf .proto file.

When you create the project using sbt new, make sure to set create_sample_code to no. That way you can start with an empty project, and gradually fill in the implementation as you follow the tutorial.

Write the Protobuf protocol

We’re going to start by writing a .proto file containing a couple of messages. These messages will be used as the request and response types for a gRPC endpoint later.

Copy the following Protobuf protocol and save it as protocol/src/main/resources/proto/hello.proto:

syntax = "proto3";

package com.example;

message HelloRequest {
  string name = 1;
}

message HelloResponse {
  string greeting = 1;
  bool happy = 2;
}

Generate Scala code

Now we have a .proto file, we can generate Scala code from it.

Start sbt and run the muSrcGen task. You should see some Protobuf-related log output:

sbt:hello-mu-protobuf> muSrcGen
protoc-jar: protoc version: 3.11.1, detected platform: osx-x86_64 (mac os x/x86_64)
protoc-jar: embedded: bin/3.11.1/protoc-3.11.1-osx-x86_64.exe
protoc-jar: executing: [/var/folders/33/gbkw7lt97l7b38jnzh49bwvh0000gn/T/protocjar11045051115974206116/bin/protoc.exe, --proto_path=/Users/chris/code/hello-mu-protobuf/protocol/target/scala-2.12/resource_managed/main/proto/proto, --proto_path=/Users/chris/code/hello-mu-protobuf/protocol/target/scala-2.12/resource_managed/main/proto, --plugin=protoc-gen-proto2_to_proto3, --include_imports, --descriptor_set_out=hello.proto.desc, hello.proto]

Let’s have a look at the code that Mu-Scala has generated. Open the file protocol/target/scala-2.12/src_managed/main/com/example/hello.scala in your editor of choice.

It’s generated code, so it will look pretty ugly. Here’s a version of it tidied up a bit to make it more readable:

package com.example

import higherkindness.mu.rpc.protocol._

object hello {
  final case class HelloRequest(@pbIndex(1) name: String)
  final case class HelloResponse(@pbIndex(1) greeting: String, @pbIndex(2) happy: Boolean)
}

A few things to note:

  • Mu-Scala has generated one case class for each Protobuf message
  • The package name matches the one specified in the .proto file
  • The case classes are inside an object whose name matches the filename of hello.proto

Add an RPC service

We now have some model classes to represent our RPC request and response, but we don’t have any RPC endpoints. Let’s fix that by adding a service to the Protobuf protocol.

Add the following lines at the end of hello.proto to define an RPC service with one endpoint:

service Greeter {
  rpc SayHello (HelloRequest) returns (HelloResponse);
}

Regenerate the code

If you run the muSrcGen sbt task again, and inspect the protocol/target/scala-2.12/src_managed/main/com/example/hello.scala file again, it should look something like this:

package com.example

import higherkindness.mu.rpc.protocol._

object hello {
  final case class HelloRequest(@pbIndex(1) name: String)
  final case class HelloResponse(@pbIndex(1) greeting: String, @pbIndex(2) happy: Boolean)

  @service(Protobuf, Identity, namespace = Some("com.example"), methodNameStyle = Capitalize)
  trait Greeter[F[_]] {
    def SayHello(req: HelloRequest): F[HelloResponse]
  }

}

A trait has been added to the generated code, corresponding to the service we added to hello.proto.

There’s quite a lot going on there, so let’s unpack it a bit.

  • The trait is called Greeter, which matches the service name in the .proto file.
  • The trait contains a method for each endpoint in the service.
  • Mu-Scala uses “tagless final” encoding: the trait has a higher-kinded type parameter F[_] and all methods return their result wrapped in F[...].
    • As we’ll see in a later tutorial, F[_] becomes an IO monad such as cats-effect IO when we implement a gRPC server or client.
  • The trait is annotated with @service. This is a macro annotation. When we compile the code, it will create a companion object for the trait containing a load of useful helper methods for creating servers and clients. We’ll see how to make use of these helpers in the next tutorial.
  • The annotation has 4 parameters:
    1. Protobuf describes how gRPC requests and responses are serialized
    2. Identity means GZip compression of requests and responses is disabled
    3. "com.example" is the namespace in which the RPC endpoint will be exposed
    4. Capitalize means the endpoint will be exposed as SayHello, not sayHello.

These parameters can be customised using sbt settings. Take a look at the source generation reference for more details.

Next steps

To find out how to turn this service definition into a working gRPC client or server, continue to the gRPC server and client tutorial.
